Platform Pier Arm Erection For Pune Metro Line 3 Begins On Baner Road

Share this News:

Pune, April 13, 2023: The overall work of the Pune Metro Line 3 project connecting the IT hub of Hinjewadi with the central hub of Shivajinagar has gained sustained momentum across several sections now. Along with the viaduct, work for the station pier building is in full swing and the first side arm of Platform Pier Arm (PPA) of proposed station no. 18 (PMR 18) of Pune Metro Line 3 was erected today morning opposite YASHADA (Baner Road). Each station pier will have 2 such arms for the concourse & platform level. The commendable part is just a year ago on the same day (April 13) the very first pier of Pune Metro Line 3 was erected on Ganeshkhind Road.

What is Platform Pier Arm (PPA)?

The platform arm is a structural entity that is the structural component holding the platform from which the trains are accessed. Structurally, it is to be understood in two parts, the two branches of the cantilever on either side and the central portion (Protruding Longitudinally). Both of these differ in the nature of the forces they resist and the profile of the cables apart from their geometry.

There are many types of piers in a typical Metro Mass Transit System anywhere. A series of these piers constitute an entire metro station. Generally, these are designed as huge expanded double portals. A unique type of station pier is a singular pier with freely hanging cantilevers branching from either side, supporting the entire station upon its long protruding arms, like a tree. Station piers are the most critical piers that are designed for an elevated metro system in any city.

About Pune Metro line 3:

The Pune Metro line III is a ~23 Km elevated Metro rail project connecting the IT hub of Hinjawadi to the Central business district of Shivajinagar. It is a Public Private Partnership (PPP) project awarded by the Pune Metropolitan Region Development Authority (PMRDA) to a consortium consisting of Tata Group’s TRIL Urban Transport Private Limited (TUTPL) and Siemens Project Ventures GmbH. The Project would be developed & operated on Design, build, finance, operate & transfer (DBFOT) basis by a special purpose vehicle (SPV), Pune IT City Metro Rail Limited (PITCMRL) for a Concession Period of 35 years including the construction period.
